pynfc – A Hands-On NFC Toolkit with Flask, PySCard and ACR122U

1. Why I Built pynfc – From Black-Box Tools to Transparent Labs

NFC is everywhere: metro cards, office badges, vending machines, access systems… but the tools we use to interact with them are often black boxes. Vendor GUIs, half-documented Windows tools, or one-off C utilities that are painful to set up and almost impossible to extend.

I wanted something different for my own learning and labs:

• A small, auditable codebase written in Python.
• A simple web UI I can open from any browser on my LAN.
• Support for a cheap USB reader like the ACR122U.
• Focus on MIFARE Classic 1K operations: read, dump, write, value blocks.
• A clear, explicit place to manage keys (keys.json), not some magic registry.

pynfc is my answer: a Flask app and REST API on top of PySCard and PC/SC that makes NFC experimentation feel like using a web tool instead of fighting low-level utilities. It’s explicitly meant for lab cards that you own, not for attacking production systems.

2. Hardware, Stack & Project Layout

Before touching any code, the first constraint is always hardware and drivers. pynfc is built around the idea that the NFC reader is just another PC/SC device.

2.1 Hardware & OS Support

The reference setup looks like this:

• Reader: ACR122U (USB), or any PC/SC-compatible NFC reader.
• Tags: Focus on MIFARE Classic 1K cards (lab/test cards).
• OS: Linux (Ubuntu 22.04/24.04), Windows 10/11, macOS 12+.

On Linux, pcscd does the heavy lifting. On Windows and macOS, PC/SC support is already there; you just need the reader drivers and Python.

2.2 Tech Stack

The software stack is intentionally small and understandable:

• Flask – HTTP API and minimal web UI.
• PySCard – Python interface to PC/SC smart card stack.
• PC/SC – System-level smart card middleware (pcsc-lite on Linux).
• keys.json – JSON file with default and per-sector keys.
• mfc_default_keys.disc – wordlist of common MIFARE Classic keys for labs.

In the repo you’ll find a compact structure:

pynfc/
├─ app.py                # Flask app: endpoints + NFC operations
├─ requirements.txt      # Python dependencies
├─ keys.json             # Default & per-sector keys for your cards
├─ mfc_default_keys.disc # Optional wordlist of common test keys
├─ README.md             # Project documentation
└─ ...                   # (future) templates/, static/, dumps/ etc.

At the moment, app.py concentrates both the API and core NFC logic. As the project grows, the plan is to extract a small nfc/ package and keep Flask as an interface layer only.

2.3 What pynfc Is Not

It’s worth stating explicitly what pynfc is not trying to be:

• Not a replacement for Proxmark or hardcore RF tooling.
• Not a “click-to-hack” solution for production systems.
• Not a full-blown key cracking framework.

Instead, it’s closer to a transparent lab notebook for NFC: you can see the code, tweak flows, and connect it with other tools (logs, dashboards, teaching material, etc.).

3. Implementation – From Reader Plug-In to First Dump

Let’s walk through the main flow: installing the dependencies, wiring the reader, configuring keys and taking your first dump of a MIFARE Classic card.

3.1 Preparing the System (Linux Example)

On Linux, the flow usually starts with installing PC/SC components and verifying that the OS actually sees your reader and tag:

# 1) Install PC/SC stack and ACS CCID driver
sudo apt update
sudo apt install -y pcscd pcsc-tools libacsccid1

# 2) Start / enable the PC/SC service
sudo systemctl enable --now pcscd.socket
# or: sudo systemctl restart pcscd

# 3) Verify that the reader and tag are visible
pcsc_scan

When you see your ACR122U and a tag being detected via pcsc_scan, you know the OS and reader are good. From there, PySCard can talk to the device, and pynfc can sit above it.

3.2 Python Environment & Dependencies

Next comes the Python setup. From the repo root:

python3 -m venv .venv
source .venv/bin/activate      # Windows: .venv\Scripts\activate
pip install -U pip wheel
pip install -r requirements.txt

requirements.txt is intentionally minimal: Flask for the HTTP part and PySCard for NFC. You can always add logging, dotenv support, or other utilities as the project grows.

Under the hood, a typical PySCard snippet looks like this:

from smartcard.System import readers
from smartcard.util import toHexString

# List available PC/SC readers
r = readers()
if not r:
    raise RuntimeError("No PC/SC readers found")

reader = r[0]
connection = reader.createConnection()
connection.connect()

# Simple APDU example: get card ATR
atr = connection.getATR()
print("Reader:", reader)
print("ATR:", toHexString(atr))

pynfc wraps this core flow and adds higher-level operations for MIFARE Classic tags: selecting a sector, authenticating with the right key, then reading/writing blocks and saving dumps.

3.3 keys.json – Making Keys Explicit

One of the first things I wanted was a clear, versionable place to store default keys and per-sector overrides. That’s what keys.json is for:

{
  "default_key_type": "A",
  "default_key_hex": "FFFFFFFFFFFF",
  "candidate_keys": [
    "FFFFFFFFFFFF",
    "A0A1A2A3A4A5",
    "B0B1B2B3B4B5"
  ],
  "per_sector_keys": {
    "0": { "A": "FFFFFFFFFFFF", "B": "FFFFFFFFFFFF" },
    "1": { "A": "FFFFFFFFFFFF" },
    "9": { "B": "1848A8D1E4C5" }
  }
}

The app reads this file on startup and uses it when trying to authenticate sectors during a dump or a targeted read. That makes testing repeatable: every time you come back to the lab, the keys are exactly where you left them.

For anything sensitive, you can keep a private version of keys.json outside version control and mount it or inject it via environment variables in production.

3.4 Running pynfc & Taking a First Dump

Once the dependencies and keys are ready, running pynfc is straightforward:

export FLASK_APP=app.py
export FLASK_ENV=development  # or production
flask run  # or: python app.py

By default, Flask will bind to http://127.0.0.1:5000. From here you have two options:

• Use a minimal web UI (when templates/static are present) to scan, read and dump.
• Hit the REST endpoints directly with curl or a tool like Hoppscotch/Postman.

An example of what a REST-style flow could look like:

# List readers
curl http://localhost:5000/api/readers

# Poll for a card and read basic info
curl http://localhost:5000/api/tag/info

# Dump a full MIFARE Classic 1K card to a file under dumps/
curl -X POST http://localhost:5000/api/tag/dump \
     -H "Content-Type: application/json" \
     -d '{"format": "json"}'

Dumps are stored under a dumps/ directory (by timestamp or UID) so you can come back later, compare states, or restore them onto another card for lab scenarios.

4. Lab Scenarios & What I Learned About NFC

Writing pynfc wasn’t just a coding exercise – it forced me to properly understand how MIFARE Classic and PC/SC behave in practice. A few of the lab scenarios I’ve played with:

• Baseline dumps: take a dump of a fresh lab card, perform an action (tap on a door, buy something), then dump again and diff the results.
• Value blocks: decode how counters are stored, incremented and mirrored across blocks with the value block format.
• Sector-level access: see exactly which sectors are open/closed with default keys versus custom keys.
• Card cloning (for labs): duplicate the state of one lab card into another and verify that behaviour is preserved in a test environment.

A few key lessons:

• Good logs matter: when dealing with keys and auth failures, clear logs are the difference between “this card is broken” and “you’re using the wrong key for sector 9”.
• PC/SC quirks are real: some readers or OSes behave slightly differently around timeouts and reconnects – you have to handle that gracefully in code.
• Legal & ethical boundaries are important: having your own cards and a lab is the only sane way to learn NFC without causing trouble.

pynfc sits nicely in that space: a teaching and exploration tool that is small enough to read end-to-end, while still being useful for day-to-day experiments.

5. Next Steps – Where pynfc Can Go

Right now, pynfc is a solid starting point. But there are plenty of directions it can grow:

• Proper web UI: Tailwind-based UI with live logs, tag status, and “one-click” dump/restore buttons.
• Per-lab profiles: separate configurations for different lab scenarios (e.g., transit card lab, office access lab, test vending machine lab).
• Integration with other projects: export NFC data into other tools, or use a card as a physical token for side projects (time tracking, homelab access, etc.).
• More tag types: basic support for other chip families (read-only info, UID scanning, etc.), still keeping the UI simple.
• Better safety rails: “read-only” mode, confirmation prompts for dangerous operations, and per-endpoint access control.

The goal is to keep pynfc opinionated but hackable: you can clone the repo, understand it in an afternoon, and then bend it to your own NFC lab needs without feeling like you’re fighting a framework.
